FPT IVECO NEF – N45 Piston #87317238

PRINT THIS PAGE
AVAILABLE EQUIPMENT MODELS
Engine Model: N45
Engine Desc: NATURALLY ASPIRATED
Engine Data:

Tier 3 –  2 Valves per Cylinder
Engine Info: 4 Cyl
Engine Dimensions:

Bore: 4.095in / 104.00mm

Stroke: 5.196in / 132.00mm

Displacement: 274.607 in3 /4.5 Lt
    CLOSE
    Equipment Models

    CASE IH - IRRIGATION POWER UNIT

    • PX70

    CASE IH - SKID STEER

    • 430
    • 445

    CASE IH - COMPACT TRACK LOADER

    • 445CT
    • 450CT

    CASE IH - BACKHOE LOADER

    • 580M SERIES 2

    CASE IH - TRACTOR

    • JX1070U
    • JX1080U
    • JX1085C

    CASE IH - BACKHOE LOADER

    • 580M SERIES 2

    NEW HOLLAND - TRACTOR

    • 5610S
    • 6610S
    • 7610S
    • TN85A
    • TN85DA

    Engine Model

    • F4DFE613G
  • Basic Kit
    FOK7238/4 Std. (1) Click to view kit content
    CLOSE
    Item #:
    Quantity:
    Description:
    F87317238
    4
    PISTON & RING KIT, Std
    F2995787
    4
    BEARING, MAIN PAIR, Std
    F8093882
    4
    BEARING, CONNECTING ROD PAIR, Std
    F2995784
    1
    BEARING, THRUST PAIR, Std
    F4890832
    1
    SEAL, FRONT CRANKSHAFT
    F4890833
    1
    SEAL, REAR CRANKSHAFT
    FN45OHK
    1
    GASKET SET, OVERHAUL
    F4892708
    4
    BUSHING, CONNECTING ROD
    F4895040
    1
    BUSHING, CAMSHAFT
         FOK7243/4 0.50 (1) Click to view kit content
    CLOSE
    Item #:
    Quantity:
    Description:
    F87317243
    4
    PISTON & RING KIT, 0.50 mm
    F2995787
    4
    BEARING, MAIN PAIR, Std
    F8093882
    4
    BEARING, CONNECTING ROD PAIR, Std
    F2995784
    1
    BEARING, THRUST PAIR, Std
    F4890832
    1
    SEAL, FRONT CRANKSHAFT
    F4890833
    1
    SEAL, REAR CRANKSHAFT
    FN45OHK
    1
    GASKET SET, OVERHAUL
    F4892708
    4
    BUSHING, CONNECTING ROD
    F4895040
    1
    BUSHING, CAMSHAFT
         FOK7249/4 1.00 (1) Click to view kit content
    CLOSE
    Item #:
    Quantity:
    Description:
    F87317249
    4
    PISTON & RING KIT, 1.00 mm
    F2995787
    4
    BEARING, MAIN PAIR, Std
    F8093882
    4
    BEARING, CONNECTING ROD PAIR, Std
    F2995784
    1
    BEARING, THRUST PAIR, Std
    F4890832
    1
    SEAL, FRONT CRANKSHAFT
    F4890833
    1
    SEAL, REAR CRANKSHAFT
    FN45OHK
    1
    GASKET SET, OVERHAUL
    F4892708
    4
    BUSHING, CONNECTING ROD
    F4895040
    1
    BUSHING, CAMSHAFT
    Inframe Kit
    FIK7238/4 (1) Click to view kit content
    CLOSE
    Item #:
    Quantity:
    Description:
    F87317238
    4
    PISTON & RING KIT, Std
    F2995787
    4
    BEARING, MAIN PAIR, Std
    F8093882
    4
    BEARING, CONNECTING ROD PAIR, Std
    F2995784
    1
    BEARING, THRUST PAIR, Std
    FN45IFK
    1
    GASKET SET, TOP
         FIK7243/4 (1) Click to view kit content
    CLOSE
    Item #:
    Quantity:
    Description:
    F87317243
    4
    PISTON & RING KIT, Std
    F2995787
    4
    BEARING, MAIN PAIR, Std
    F8093882
    4
    BEARING, CONNECTING ROD PAIR, Std
    F2995784
    1
    BEARING, THRUST PAIR, Std
    FN45IFK
    1
    GASKET SET, TOP
         FIK7249/4 (1) Click to view kit content
    CLOSE
    Item #:
    Quantity:
    Description:
    F87317249
    4
    PISTON & RING KIT, Std
    F2995787
    4
    BEARING, MAIN PAIR, Std
    F8093882
    4
    BEARING, CONNECTING ROD PAIR, Std
    F2995784
    1
    BEARING, THRUST PAIR, Std
    FN45IFK
    1
    GASKET SET, TOP
  • 1) Piston & Ring Kit
    F87317238 Std. F87317243 0.40mm F87317249 0.80mm
    2) Ring Set
    F87316211 Std. F87316213 0.40mm F87316214 0.80mm
    4 Per Engine
  • Main Bearing
    F2995787 Std F2995788 .254mm F2995789 .508mm
    Use 4 Pairs per engine
  • Con Rod Bearing
    F8093882 Std. F8094960 .254mm F8094961 .508mm
    Use 4 Pairs per engine
  • Thrust Bearing
    F2995784 Std. F2995785 .254mm F2995786 .508mm
    Use 1 pair per engine
  • 1) Front Crankshaft Seal
    F4890832
    2) Rear Crankshaft Seal
    F4890833
  • 1) O/H Gasket Set
    FN45OHK (1)
    2) Top Gasket Set
    FN45IFK (2)
    3) Head Gasket
    F2830920 1.15mm Thick F2830919 1.25mm Thick
    4) Valve Cover Gasket
    F2852033 x4
    5) Oil Pan Gasket
    F2852012 Paper F4897877 Rubber F4894295 Metal
    6) Exhaust Manifold Gasket
    F2852743 x4
    7) Intake Manifold Gasket
    F4899921 x2
    8) Injection Pump Gasket
    F2852885 x1
  • 1) Bush, Con Rod
    F4892708 x4
    2) Connecting Rod
    F2831298 x4
    3) Connecting Rod Bolt
    F2831297 x8
    4) Head Bolts
    F4892861 F4892859
  • 1) Bushing Camshaft
    F4895040 x1
    2) Tappet
    F4895180 x8
    3) Pushrod
    F4895361 x8
Valve Section
(1): The kit includes Head Gasket (F2830923) – 1.15mm thick. It does not include the oil pan gasket; please order it separately.
(2): Set contains Head Gasket F2830923 – 1.15mm Thick.
(3): Verify Application.
(3): Check application for proper usage.
